Property Details
![100 Kimball Drive logos_FINAL-03.png](https://static.wixstatic.com/media/9baedc_03f67caa1550451da5526aea6434a25d~mv2.png/v1/fill/w_166,h_38,al_c,q_85,usm_1.20_1.00_0.01,enc_auto/100%20Kimball%20Drive%20logos_FINAL-03.png)
Building Size
175,000 square feet on 13-acre manicured site
​5 floors and lower garage level
Parking
638 spaces total
558 surface and 80 lower garage level
Finished Ceiling Heights
9 foot
Utilities
-
Electricity: Jersey Central Power & Light
-
Water/Sewer: Township of Parsippany
-
Natural Gas: New Jersey Natural Gas
-
Telecommunications: Verizon
Building Generator
125 KW Natural gas (Base Building system)
500 KW Diesel (tenant system)
Fire Protection/ Life Safety
-
Wet type fire protection sprinkler system, controlled by a monitored fire alarm system.
-
Also includes battery pack, emergency lights and exit lighting, audible and visual fire alarm devices, control panel, smoke detectors and manual pull stations.
​
Year Built
2007
Planned renovations 2022
Security
Monday through Friday
System consists of card key access and CCTV cameras by entrances and elevator lobby and 4 emergency call stations in parking garage
Loading
Dedicated loading area - one full size dock with dock leveler
Electrical
Building is served by a 277/480 volt, 3-phase, 4-wire service from JCP&L with a pad-mounted transformer
HVAC
-
​Two mechanical penthouses with variable air volume distribution, high efficiency, rotary screw refrigeration plant and evaporatively cooled condenser.
-
System distributes chilled air to each floor individually
-
Enthalpy economizer control system, which provides outdoor air for cooling during mild weather
-
Air distribution is controlled by fan powered VAV terminals with electric heating coils at the perimeter
-
System is controlled by a Direct Digital Computer system, with the ability to be controlled remotely
![dji_0778-dji_0782_edited.jpg](https://static.wixstatic.com/media/9baedc_f380e2aeb091420788d4c2daceb6b1b3~mv2.jpg/v1/crop/x_74,y_5,w_1281,h_1773/fill/w_486,h_667,al_c,q_80,usm_1.20_1.00_0.01,enc_auto/dji_0778-dji_0782_edited.jpg)
Site Plan
